Pro Weld - Welder/Generator - 200amp
$2132.99
Categories | Generators |
Brand | Pro Weld |
Capacity | 12.5 L |
Fuel Type | Diesel |
Model | KDW230AC |
Rated Voltage | 220.0 V |
Rated Frequency | 50.0 Hz |
Max Power Output | 7500.0 W |
What's in the box | 1x Welder/Generator - 200amp |
Rated Power Output | 6000.0 W |
Engine Displacement | 499.0 cc |
Basic Colours | Black, Red |
Barcode | 9991201379679 |
Features:
Welder generator type: inverter type-thin sheets can be welded
Model: KDW230AC
Power: 6KW
Rated voltage: 220V
Rated frequency: 50hz
Phase number: 1-Phase
Power factor: 1.0
Work voltage: 25-30V
Rated welding current: 200A
Current regulation range: 20-220A
Welding load continuous ratio 85%
Insulation grade: H
Engine Model: DIESEL 192F
Engine type: 1-Cylinder,4 strokes, air-cooled diesel engine
Broke stroke: 92x75mm
Displacement: 499cc
Compression ratio: 19.5:1
Ration Rotation Speed: 3000rpm
Rated power: 7.5kw
Starting System: electric start
Fuel type: diesel fuel
Fuel tank capacity: 12.5L
Fuel consumption: 2.1L/h
Lubrication oil: CD Grade or higher (SAE10W/30, SAE15W/40)
Lube: 16.5L
Wheels: with
Welding electrode diameter: 4.0mm
Noise level: 83dB (A)
Product dimension: 720x500x620mm(LxWxH)
Net weight:120kg
